Allen-Bradley PanelView Plus 6 700

22 Rockwell Automation Publication 2711P-UM006A-EN-P - November 2010
Chapter 1 Overview
2711P-RY2032 Replacement battery 1
2711P-RTBAC3 AC power terminal block 10
2711P-RTBDC2 2-pin DC power terminal block 10
Table 19 - Bezel Replacements
Cat. No. Terminal Model
Operator Input
Keypad Touch Key/Touch
2711P-RBK7
700
•
2711P-RBT7 •
2711P-RBB7 •
2711P-RBK10
1000
•
2711P-RBT10 •
2711P-RBB10 •
2711P-RBK12
1250
•
2711P-RBT12 •
2711P-RBT12H
(1)
(1) Applies to the cat. no. 2711P-RDT12H 1250 high-bright display module.
•
2711P-RBB12 •
2711P-RBK15
1500
•
2711P-RBT15 •
2711P-RBB15 •
Table 20 - Adapter Plates
Cat. No,
Adapts This
PanelView Plus 6 Terminal
To This Terminal Cutout
2711P-RAK7 700 keypad or keypad/touch PanelView Standard 900 keypad
2711P-RAT7 700 touch PanelView Plus 900 touch
2711P-RAK10 1000 keypad or keypad/touch PanelView 1000/1000e keypad
2711P-RAT10 1000 touch PanelView 1000/1000e touch
2711P-RAK15 1500 keypad or keypad/touch PanelView 1200e/1400e keypad
2711P-RAT15 1500 touch PanelView 1200e/1400e touch
2711P-RAK12E 1250 keypad
(1)
(1) Applies also to PanelView 1000/1000e keypad or keypad/touch terminals.
PanelView 1200/1400e keypad
2711P-RAT12E2 1250 touch
(2)
(2) Applies also to PanelView 1000/1000e touch terminals.
PanelView 1200 touch
2711P-RAT12E 1250 touch
(2)
PanelView 1200e/1400e touch
2711P-RAK12S 1250 keypad
(1)
or keypad/touch PanelView Standard 1400 keypad
2711P-RAT12S 1250 touch
(2)
PanelView Standard 1400 touch
Table 18 - Power Supply and Power Terminal Blocks
Cat. No, Description Quantity
