Rockwell Automation Publication 750-IN001O-EN-P - October 2014 141
Lift and Mount the Drive Chapter 3
Cabinet Options Assembly – Floor Mount Frames 9 and 10
Use the two handles on each side of cabinet options assembly to slowly and
smoothly pull the assembly on to the Roll-out Cart.
Refer to page 128
for information on related electrical connections.
