Rockwell Automation Publication 750-IN001O-EN-P - October 2014 253
I/O Wiring Chapter 5
Digital Output
Internal supply
20-750-1133C-1R2T
Main Control Board TB1
11-Series I/O Module TB2
• Set Selection
Port X (11-Series I/O Module): P20 [TO0 Sel] = Port 0: P935 [Drive Status 1], bit 7 = Faulted
• View Results
Port X (11-Series I/O Module): P5 [Dig Out Sts]
Digital Output
External supply
20-750-1133C-1R2T
PLC TB 11-Series I/O Module TB2
• Set Selection
Port X (11-Series I/O Module): P20 [TO0 Sel] = Port 0: P935 [Drive Status 1], bit 7 = Faulted
• View Results
Port X (11-Series I/O Module): P5 [Dig Out Sts]
11-Series I/O Module TB1 Wiring Examples (Continued)
Input/Output Connection Example Required Parameter Changes
24VC
+24V
T0
TC
T1
+24V
24VC
753 755
P3
P8
3
1
3
1
+24V Common
T0
TC
T1
T0
TC
T1
OR
+24VDC
Common
PLC
1756-1B16
IN-9
IN-11
IN-13
IN-15
GND-1
IN-1
IN-3
IN-5
IN-7
GND-0
IN-8
IN-10
IN-12
IN14
GND-1
IN-0
IN-2
IN-4
IN-6
GND-0
