Allen-Bradley PowerFlex 4 User Manual

Accessories and Dimensions B-7
Figure B.4 PowerFlex 4 Cutout Dimensions – Dimensions are in millimeters and
(inches)
195
(7.68)
97.5
(3.84)
179
(7.05)
8
(0.31)
130
(5.12)
114
(4.49)
5.3
(0.21)
8
(0.31)
98
(3.86)
49
(1.93)
16
(0.63)
210
(8.27)
98
(3.86)
160
(6.30)
145
(5.71)
49
(1.93)
31
(1.22)
7.5
(0.30)
14
(0.55)
98.5
(3.88)
197
(7.76)
6.5
(0.26)
225
(8.86)
23.5
(0.93)
5.3
(0.21)
Frame A
Frame B

Allen-Bradley PowerFlex 4 Specifications

General

Series	PowerFlex 4
Horsepower	0.2-3 HP
Enclosure	IP20
Output Frequency	0-400 Hz
Power Range	0.2…2.2 kW (0.25…3 HP)
Communication Options	RS-485
Storage Temperature	-40…85 °C (-40…185 °F)
Relative Humidity	5-95% non-condensing
Control Method	Volts per Hertz
