Rockwell Automation Publication 520-UM001A-EN-E - February 2013 145
Supplemental Drive Information Appendix A
Category Specifications
Protection Bus Overvoltage Trip
100...120V AC Input:
200...240V AC Input:
380...480V AC Input:
525...600V AC Input:
405V DC bus (equivalent to 150V AC incoming line)
405V DC bus (equivalent to 290V AC incoming line)
810V DC bus (equivalent to 575V AC incoming line)
1005V DC bus (equivalent to 711V AC incoming line)
Bus Undervoltage Trip
100...120V AC Input:
200...240V AC Input:
380...480V AC Input:
525...600V AC Input
P038 = 3 “600V”:
P038 = 2 “480V”:
190V DC bus (equivalent to 75V AC incoming line)
190V DC bus (equivalent to 150V AC incoming line)
390V DC bus (equivalent to 275V AC incoming line)
487V DC bus (equivalent to 344V AC incoming line)
390V DC bus (equivalent to 275V AC incoming line)
Power Ride-Thru: 100 ms
Logic Control Ride-Thru: 0.5 s minimum, 2 s typical
Electronic Motor Overload Protection: I
2
t protection – 150% for 60 s, 200% for 3 s (Provides Class
10 protection)
Overcurrent: 200% hardware limit, 300% instantaneous fault
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Environment Altitude:
Without derating:
With derating:
1000 m (3300 ft) max.
Up to 4000 m (13,200 ft) max., with the exception of 600V
drives at 2000 m (6600 ft) max. See Current Derating Curves
on page 13 for derating guidelines.
Max. Surrounding Air Temperature
Without derating:
With derating:
-20...50 °C (-4...122 °F)
-20...60 °C (-4...140 °F) or -20...70 °C (-4...158 °F) with
optional Control Module Fan kit. See Current Derating
Curves on page 13 for derating guidelines.
Storage Temperature:
Frame A...D:
Frame E:
-40...85 °C (-40...185 °F)
-40...70 °C (-40...158 °F)
Atmosphere:
Relative Humidity: 0...95% noncondensing
Shock:
Vibration:
Complies with IEC 60068-2-27
Complies with IEC 60068-2-6:1995
Conformal Coating: Complies with:
IEC 60721-3-3 to level 3C2 (chemical gases only)
Surrounding Environment Pollution
Degree
Pollution Degree 1 & 2:
See Pollution Degree Ratings According to EN 61800-5-1
on
page 42 for descriptions.
All enclosures acceptable.
Drive must not be installed in an area where the ambient atmosphere
contains volatile or corrosive gas, vapors or dust. If the drive is not going to be
installed for a period of time, it must be stored in an area where it will not be
exposed to a corrosive atmosphere.
Frame
Size
Operating and Nonoperating Nonoperating (Transportation)
Force
(Shock/Vibration) Mounting Type
Force
(Shock/Vibration) Mounting Type
A 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
B 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
C 15 g / 2 g DIN rail or screw 30 g/ 2.5 g Screw only
D 15 g / 2 g Screw only 30 g/ 2.5 g Screw only
E 15 g / 1.5 g Screw only 30 g/ 2.5 g Screw only
