Allen-Bradley PowerFlex 525 User Manual

Rockwell Automation Publication 520-UM001A-EN-E - February 2013 151
Accessories and Dimensions Appendix B
(1) The resistors listed in this tables are rated for 5% duty cycle.
(2) Use of Rockwell Automation resistors is always recommended. The resistors listed have been carefully selected for optimizing
performance in a variety of applications. Alternative resistors may be used, however, care must be taken when making a selection.
See the PowerFlex Dynamic Braking Resistor Calculator, publication PFLEX-AT001.
(3) Requires two resistors wired in parallel.
(4) Requires three resistors wired in parallel.
Dynamic Brake Resistors
Drive Ratings Minimum
Resistance
Ω ±10%
Resistance
Ω ±5% Catalog No.
(1)(2)
Input Voltage HP kW
100...120V
50/60 Hz
1-Phase
0.5 0.4 60 91 AK-R2-091P500
1.00.756091AK-R2-091P500
1.5 1.1 48 91 AK-R2-091P500
200...240V
50/60 Hz
1-Phase
0.5 0.4 60 91 AK-R2-091P500
1.00.756091AK-R2-091P500
2.0 1.5 48 91 AK-R2-091P500
3.0 2.2 32 47 AK-R2-047P500
200...240V
50/60 Hz
3-Phase
0.5 0.4 60 91 AK-R2-091P500
1.00.756091AK-R2-091P500
2.0 1.5 60 91 AK-R2-091P500
3.0 2.2 32 47 AK-R2-047P500
5.0 3.7 19 47 AK-R2-047P500
7.5 5.5 19 30 AK-R2-030P1K2
10.0 7.5 15 30 AK-R2-030P1K2
15.0 11.0 15 15 AK-R2-030P1K2
(3)
20.0 15.0 11 15 AK-R2-030P1K2
(3)
380...480V
50/60 Hz
3-Phase
0.5 0.4 97 360 AK-R2-360P500
1.0 0.75 97 360 AK-R2-360P500
2.0 1.5 97 360 AK-R2-360P500
3.0 2.2 97 120 AK-R2-120P1K2
5.0 4.0 77 120 AK-R2-120P1K2
7.5 5.5 55 120 AK-R2-120P1K2
10.0 7.5 55 120 AK-R2-120P1K2
15.0 11.0 50 60 AK-R2-120P1K2
(3)
20.0 15.0 50 60 AK-R2-120P1K2
(3)
25.0 18.5 30 40 AK-R2-120P1K2
(4)
30.0 22.0 30 40 AK-R2-120P1K2
(4)
525...600V
50/60 Hz
3-Phase
0.5 0.4 120 360 AK-R2-360P500
1.0 0.75 120 360 AK-R2-360P500
2.0 1.5 120 360 AK-R2-360P500
3.0 2.2 120 120 AK-R2-120P1K2
5.0 3.7 82 120 AK-R2-120P1K2
7.5 5.5 65 120 AK-R2-120P1K2
10.0 7.5 65 120 AK-R2-120P1K2
15.0 11.0 65 60 AK-R2-120P1K2
(3)
20.0 15.0 65 60 AK-R2-120P1K2
(3)
25.0 18.5 60 60 AK-R2-120P1K2
(3)
30.0 22.0 38 40 AK-R2-120P1K2
(4)

Allen-Bradley PowerFlex 525 Specifications

General

Horsepower	0.5-30 HP
kW	0.4-22 kW
Input Voltage	200-240V AC, 380-480V AC
Enclosure	IP20, NEMA/UL Type 1
Communications	EtherNet/IP
Control Methods	V/Hz, Sensorless Vector
STO	Safe Torque Off (STO)
Output Voltage	0-Input Voltage
Operating Temperature	-20°C to 50°C (-4°F to 122°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Relative Humidity	5-95% non-condensing
Dimensions	Varies by model
Weight	Varies by model
