152 Rockwell Automation Publication 520-UM001A-EN-E - February 2013
Appendix B Accessories and Dimensions
EMC Line Filters
Drive Ratings
Frame Size Catalog No.Input Voltage HP kW Current (A)
100...120V
50/60 Hz
1-Phase
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 B 25-RF023-BL
1.5 1.1 6.0 B 25-RF023-BL
200...240V
50/60 Hz
1-Phase
0.5 0.4 2.5 A 25-RF011-AL
1.0 0.75 4.8 A 25-RF011-AL
2.0 1.5 8.0 B 25-RF023-BL
3.0 2.2 11.0 B 25-RF023-BL
200...240V
50/60 Hz
3-Phase
0.5 0.4 2.5 A 25-RF014-AL
1.0 0.75 5.0 A 25-RF014-AL
2.0 1.5 8.0 A 25-RF014-AL
3.0 2.2 11.0 A 25-RF014-AL
5.0 3.7 17.5 B 25-RF021-BL
7.5 5.5 24.0 C 25-RF027-CL
10.0 7.5 32.2 D 25-RF035-DL
15.0 11.0 48.3 E 25-RF056-EL
20.0 15.0 62.1 E 25-RF056-EL
380...480V
50/60 Hz
3-Phase
0.5 0.4 1.4 A 25-RF7P5-AL
1.0 0.75 2.3 A 25-RF7P5-AL
2.0 1.5 4.0 A 25-RF7P5-AL
3.0 2.2 6.0 A 25-RF7P5-AL
5.0 4.0 10.5 B 25-RF014-BL
7.5 5.5 13.0 C 25-RF018-CL
10.0 7.5 17.0 C 25-RF018-CL
15.0 11.0 24.0 D 25-RF033-DL
20.0 15.0 30.0 D 25-RF033-DL
25.0 18.5 37.0 E 25-RF039-EL
30.0 22.0 43.0 E 25-RF039-EL
(1)
(1) EMC Line Filter size is based on the input current of the drive. See the tables on page 20 and page 21 for more information.
525...600V
50/60 Hz
3-Phase
0.5 0.4 0.9 A 25-RF8P0-BL
1.0 0.75 1.7 A 25-RF8P0-BL
2.0 1.5 3.0 A 25-RF8P0-BL
3.0 2.2 4.2 A 25-RF8P0-BL
5.0 3.7 6.6 B 25-RF8P0-BL
7.5 5.5 9.9 C 25-RF014-CL
10.0 7.5 12.0 C 25-RF014-CL
15.0 11.0 19.0 D 25-RF027-DL
20.0 15.0 22.0 D 25-RF027-DL
25.0 18.5 27.0 E 25-RF029-EL
30.0 22.0 32.0 E 25-RF029-EL
(1)
EMC Plates
Item Description
Frame
Size Catalog No.
EMC Plate Optional grounding plate for shielded cables. A 25-EMC1-FA
B 25-EMC1-FB
C 25-EMC1-FC
D 25-EMC1-FD
E 25-EMC1-FE
