Rockwell Automation Publication 6000-IN006F-EN-P - March 2018 31
Drive Electrical Installation Chapter 2
Figure 19 - Isolation Transformer Cabinet, Type B (Junction cabinet not applied)
Figure 20 - Isolation Transformer Cabinet, Type C (Junction cabinet applied for cable connection)
Cable clamp
Voltage Sensing
Board
Isolation Transformer
Door position
limit switches
L3 L2 L1 W V U
Incoming line power
cable connections
Outgoing motor power
cable connections
Power cable
connections to
Power Modules
L3 L1
WV U
L2
Junction
cabinet
Incoming line
power cable
connections
Outgoing motor
power cable
connections
Isolation
Transformer
Front View Side View
