Rockwell Automation Publication 6000-IN006F-EN-P - March 2018 55
Power Cabling and Control Signal Wiring Details Appendix D
Standard Input/Output
Connection Points
Table 15 - Standard I/O Connections Points
Serial Number Name of I/O Connection AI AO DI DO Note
1 Input circuit breaker closing node is allowed
(917, 918)
1 Serially connected into the input circuit breaker's closing circuit
(the VFD provides passive normally open points, valid when closed)
Input circuit breaker closing node is allowed
(957, 958) (Reserved)
1 Serially connected into the input circuit breaker's closing circuit
(the VFD provides passive normally closed points, valid when open)
2 Trip connection points within the VFD
(919, 920)
1 Can be connected into input circuit breaker's closing circuit in parallel
(the VFD provides passive normally open points, valid when closed)
Trip connection points within the VFD
(959, 960) (Reserved)
1 Can be connected into input circuit breaker's closing circuit
(the VFD provides passive normally closed points, valid when open)
3 Input circuit breaker already closed
connection point (117, 119)
1 Circuit breaker's auxiliary normally open connection points (valid when closed)
4 Input vacuum contactor close (961, 962)
(Reserved)
1 Serially connected into the vacuum contactor close
(the VFD provides passive normally open points, valid when closed)
5 Emergency stop status to Input vacuum
contactor (967,968)(Reserved)
1 Serially connected into the vacuum contactor
(the VFD provides passive normally closed points, valid when open)
Emergency stop status to Input vacuum
contactor (967,968)(Reserved)
1 Serially connected into the vacuum contactor
(the VFD provides passive normally closed points, valid when open)
Table 16 - I/O Connections related to Remote Distributed Control System
Serial Number Name of I/O Connection AI AO DI DO Note
1 VFD speed regulation command (931, 931A) 1 User-provided 4...20mA
Reserved (932, 932A) 1 User-provided 4...20 mA (Reserved)
Reserved (934, 934A) 1 User-provided 4...20 mA (Reserved)
2 VFD speed feedback signal (927, 928) 1 VFD-provided 4...20mA
3 VFD current feedback signal (925, 926) 1 VFD-provided 4...20mA
4 Alternate start command signal (431, 401)
(Reserved)
1 User-provided normally open passive dry contact
(pulsed quantity, valid with 3S)
Remote DCS start command signal (449,
401)
1 User-provided normally open passive dry contact
(pulsed quantity, valid with 3S)
Alternate command signal (432, 401)
(Reserved)
1 User-provided normally closed passive dry contact
(pulsed quantity, valid with 3S)
5 Remote DCS stop command signal (450, 401) 1 User-provided normally closed passive dry contact
(pulsed quantity, valid with 3S)
6 Reserved (433, 401) 1 User-provided normally open passive dry contact
(pulsed quantity, valid with 3S)
7 Reserved (434, 401) 1 User-provided normally open passive dry contact
(pulsed quantity, valid with 3S)
8 Reserved (435, 401) 1 User-provided normally open passive dry contact (switch quantity)
Reserved (436, 401) 1 User-provided normally open passive dry contact (switch quantity)
Reserved (437, 401) 1 User-provided normally open passive dry contact (switch quantity)
Reserved (438, 401) 1 User-provided normally open passive dry contact (switch quantity)
9 Remote DCS alternate (448, 401) 1 User-provided normally open passive dry contact (switch quantity)
10 Remote DCS fault reset command (412, 401) 1 User-provided normally open passive dry contact
