Allen-Bradley PowerFlex 6000 Installation Instructions

56 Rockwell Automation Publication 6000-IN006F-EN-P - March 2018
Appendix D Power Cabling and Control Signal Wiring Details
Alternate reset command (412, 401) 1 User-provided normally open passive dry contact
11 Emergency stop button command
(1101, 1102)
1 User-provided normally closed passive dry contact
(voltage class higher than 220V AC, 5 A, switch quantity)
Emergency stop button command
(1103, 1104)
1 User-provided normally closed passive dry contact
(voltage class higher than 220V AC, 5 A, switch quantity)
12 VFD allow closing indication (901, 902) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5 A) (used for Remote DCS)
Circuit breaker closing indication (903, 904) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD alarm indication (905, 906) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD fault indication (907, 908) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD operation indication (909, 910) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD stop indication (911, 912) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD ready indication (913, 914) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
Remote control indication (915, 916) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
13 VFD allow closing indication (941, 941A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
Circuit breaker closing indication (942, 942A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD alarm indication (943,943A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD fault indication (944, 944A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD operation indication (945, 945A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD stop indication (946, 946A) 1 VFD-provided normally open passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
VFD ready indication (947, 947A) 1 VFD-provided normally closed passive dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
Remote control indication (948, 948A) 1 VFD-provided normally closed active dry contact
(voltage class ≤220V AC, 5A) (used for Remote DCS)
Table 16 - I/O Connections related to Remote Distributed Control System (Continued)
Serial Number Name of I/O Connection AI AO DI DO Note
