Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 71
Programming and Parameters Chapter 1
Selected Option Definitions – [Analog Outx Sel], [Digital Inx Sel], and
[Digital Outx Sel]
Option Description Related
At Speed Relay changes state when drive has reached commanded speed. 380
Excl Link Links digital input to a digital output if the output is set to “Input 1-6 Link.” 361
Input 1…6 Link When Digital Output 1 is set to of these (for example, Input 3 Link) in conjunction with
Digital Input 3 set to “Excl Link,” the Digital Input 3 state (on/off) is echoed in the
Digital Output 1.
380
Manual Mode Either the HIM or I/O Terminal Block (analog input) has control of the speed reference. 380
MOP Dec Decrements speed reference as long as input is closed. 361
MOP Inc Increments speed reference as long as input is closed. 361
MtrTrqCurRef Torque producing current reference. 342
Param Cntl Parameter controlled analog output enables PLC to control analog outputs through
data links. Set in [AnlgX Out Setpt], parameters 377 and 378.
342
Param Cntl Parameter controlled digital output enables PLC to control digital outputs through
data links. Set in [Dig Out Setpt], parameter 379.
342
PI Reference Reference for PI block (see Process PI for Standard Control on page 119). 342
Precharge En Forces drive into precharge state. Typically controlled by auxiliary contact on the
disconnect at the DC input to the drive.
361
Run Level Provides a run level input. They do not require a transition for enable or fault, but a
transition is still required for a stop.
RunFwd Level
RunRev Level
Run w/Comm Enables the comms start bit to operate like a run with the run input on the terminal
block. Ownership rules apply.
SpdFdBk NoFilt Provides an unfiltered value to an analog output. The filtered version “Speed Fdbk”
includes a 125 ms filter.
342
Sync Enable The fiber feature Synchronized Speed Change has been enabled. Enables a coordinated
change in drive speeds to change machine speed.
622
Torque Est Calculated percentage of rated motor torque. 342
Traverse Enable The Traverse function has been enabled. This adds a triangle wave and square wave
modulation to the speed reference.
623
624
625
626
