22 PowerFlex 700 Adjustable Frequency AC Drive Quick Start
SPEED COMMAND
Speed Reference
091 [Speed Ref A Hi]
Scales the upper value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
[Maximum Speed]
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
079
082
092 [Speed Ref A Lo]
Scales the lower value of the [Speed Ref
A Sel] selection when the source is an
analog input.
Default:
Min/Max:
Units:
0.0
–/+[Maximum Speed]
0.1 Hz
0.01 RPM
079
081
Discrete Speeds
101
102
103
104
105
106
107
[Preset Speed 1]
[Preset Speed 2]
[Preset Speed 3]
[Preset Speed 4]
[Preset Speed 5]
[Preset Speed 6]
[Preset Speed 7]
Provides an internal fixed speed
command value. In bipolar mode
direction is commanded by the sign of
the reference.
Default:
Min/Max:
Units:
5.0 Hz/150 RPM
10.0 Hz/300 RPM
20.0 Hz/600 RPM
30.0 Hz/900 RPM
40.0 Hz/1200 RPM
50.0 Hz/1500 RPM
60.0 Hz/1800 RPM
–/+[Maximum Speed]
0.1 Hz
1 RPM
079
090
093
DYNAMIC CONTROL
Ramp Rates
140
141
[Accel Time 1]
[Accel Time 2]
Sets the rate of accel for all speed
increases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
142
143
146
361
thru
366
142
143
[Decel Time 1]
[Decel Time 2]
Sets the rate of decel for all speed
decreases.
Default:
Min/Max:
Units:
10.0 Secs
10.0 Secs
0.1/3600.0 Secs
0.1 Secs
140
141
146
361
thru
366
146 [S Curve %]
Sets the percentage of accel or decel
time that is applied to the ramp as S
Curve. Time is added, 1/2 at the
beginning and 1/2 at the end of the ramp.
Default:
Min/Max:
Units:
0%
0/100%
1%
140
thru
143
Load Limits
148 [Current Lmt Val]
Defines the current limit value when
[Current Lmt Sel] = “Cur Lim Val.”
Default:
Min/Max:
Units:
[Rated Amps] × 1.5
(Equation yields approxi-
mate default value.)
Based on Drive Rating
0.1 Amps
147
149
150 [Drive OL Mode]
Selects the drive’s response to
increasing drive temperature.
Default:
Options:
3
0
1
2
3
“Both–PWM 1st”
“Disabled”
“Reduce CLim”
“Reduce PWM”
“Both–PWM 1st”
219
File Group No.
Parameter Name & Description Values
Related
Vector
Vector
Vector
Vector
Vector
Vector
Vector
Vector
Vector
Vector
Max Speed
Accel Time
Accel Rate
=
Max Speed
Decel Time
Decel Rate
=
