Supplemental Drive Information A-5
Logic Command/Status Words
Figure A.1 Logic Command Word
Logic Bits
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Command Description
xStop
(1)
0 = Not Stop
1 = Stop
xStart
(1)(2)
0 = Not Start
1 = Start
x Jog 0 = Not Jog
1 = Jog
xClear
Faults
0 = Not Clear Faults
1 = Clear Faults
x x Direction 00 = No Command
01 = Forward Command
10 = Reverse Command
11 = Hold Present Direction
x Local
Control
0 = No Local Control
1 = Local Control
x MOP
Increment
0 = Not Increment
1 = Increment
x x Accel Rate 00 = No Command
01 = Use Accel Time 1
10 = Use Accel Time 2
11 = Use Present Time
x x Decel Rate 00 = No Command
01 = Use Decel Time 1
10 = Use Decel Time 2
11 = Use Present Time
x x x Reference
Select
(3)
000 = No Command
001 = Ref. 1 (Ref A Select)
010 = Ref. 2 (Ref B Select)
011 = Ref. 3 (Preset 3)
100 = Ref. 4 (Preset 4)
101 = Ref. 5 (Preset 5)
110 = Ref. 6 (Preset 6)
111 = Ref. 7 (Preset 7)
x MOP
Decrement
0 = Not Decrement
1 = Decrement
(1)
A “0 = Not Stop” condition (logic 0) must first be present before a “1 = Start” condition will
start the drive. The Start command acts as a momentary Start command. A “1” will start the
drive, but returning to “0” will not
stop the drive.
(2)
This Start will not function if a digital input (parameters 361-366) is programmed for 2-Wire
Control (option 7, 8 or 9).
(3)
This Reference Select will not function if a digital input (parameters 361-366) is programmed
for “Speed Sel 1, 2 or 3” (option 15, 16 or 17). Note that Reference Selection is “Exclusive
Ownership” see [Reference Owner]
on page 3-52.
