Page #96 background imageLoading...
Page #96 background image
3-52 Programming and Parameters
COMMUNICATIONS
Masks & Owners
291 [Direction Owner]
Adapter that currently has exclusive
control of direction changes.
See [Stop Owner]
. 276
thru
285
292 [Reference Owner]
Adapter that has the exclusive control of
the command frequency source
selection.
See [Stop Owner]
. 276
thru
285
293 [Accel Owner]
Adapter that has exclusive control of
selecting [Accel Time 1, 2].
See [Stop Owner]
. 140
276
thru
285
294 [Decel Owner]
Adapter that has exclusive control of
selecting [Decel Time 1, 2].
See [Stop Owner]
. 142
276
thru
285
295 [Fault Clr Owner]
Adapter that is presently clearing a fault.
See [Stop Owner]
. 276
thru
285
296 [MOP Owner]
Adapters that are currently issuing
increases or decreases in MOP
command frequency.
See [Stop Owner]
. 276
thru
285
297 [Local Owner]
Adapter that has requested exclusive
control of all drive logic functions. If an
adapter is in local lockout, all other
functions (except stop) on all other
adapters are locked out and
non-functional. Local control can only be
obtained when the drive is not running.
See [Stop Owner]
. 276
thru
285
Datalinks
300
301
[Data In A1] - Link A Word 1
[Data In A2] - Link A Word 2
Parameter number whose value will be
written from a communications device
data table.
Standard Control – Parameters that can
only be changed while drive is stopped
cannot be used as Datalink inputs.
Entering a parameter of this type will
“Disable” the link.
Vector Control – Will not be updated until
drive is stopped.
Refer to your communications option
manual for datalink information.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/387
0/544
0/611
1
302
303
[Data In B1] - Link B Word 1
[Data In B2] - Link B Word 2
See [Data In A1] - Link A Word 1 [Data
In A2] - Link A Word 2.
File
Group
No.
Parameter Name & Description
See page 3-2 for symbol descriptions
Values
Related
Vector
v3
