Allen-Bradley PowerFlex 700H Programming Manual

42 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
UTILITY
Diagnostics
234
236
[Testpoint 1 Sel]
[Testpoint 2 Sel]
Selects the function whose value is displayed in
[Testpoint x Data]. These are internal values that
are not accessible through parameters.
Note: These parameters were added for future use
in firmware revision 4.001.
Default:
Min/Max:
Units:
499
0/65535
1
235
237
[Testpoint 1 Data]
[Testpoint 2 Data]
The present value of the function
selected in [Testpoint x Sel].
Note: These parameters were added for future use
in firmware revision 4.001.
Default:
Min/Max:
Units:
Read Only
-/+32767
1
Faults
238 [Fault Config 1]
Enables/disables annunciation of the listed faults.
Setting bit 14 “Fan Cooling” to 1 configures the drive for a “Non-Resettable” fault (F32 “Fan
Cooling”). In this case, the drive must be powered-down and the cause of the fault must be
corrected before the fault can be cleared. Setting bit 14 to “0” will configure the drive for a “Non-
Configurable” alarm. In this case the drive will continue to run.
Notes: Bit 9 “Load Loss” should not be changed from “0”. Bit 10 was added for firmware revision
2.001. Bits 2 “Motor Stall” and 11 “Shear PNO Ac” were added for firmware revision 3.001. Bit 14
“Fan Cooling” was added for firmware revision 6.001.
1 = Enabled
0 = Disabled
240 [Fault Clear]
Resets a fault and clears the fault queue.
Default:
Options:
0
0
1
2
“Ready”
“Ready”
“Clear Faults”
“Clr Flt Que”
241 [Fault Clear Mode]
Enables/disables a fault reset (clear faults)
attempt from any source. This does not apply to
fault codes which are cleared indirectly via other
actions.
Default:
Options:
1
0
1
“Enabled”
“Disabled”
“Enabled”
242 [Power Up Marker]
Elapsed hours since initial drive power up. This
value will rollover to 0 after the drive has been
powered on for more than the max value shown.
For relevance to most recent power up see [Fault x
Time].
Default:
Min/Max:
Units:
Read Only
0.0000/429496.7295 Hr
0.1 Hr
244
246
248
250
252
254
256
258
File Group No.
Parameter Name & Description Values
Related
Name Reserved Fan Cooling Reserved Reserved Shear PNO Ac Gate Disable Load Loss Phase Loss Motor Therm Decel Inhib AutRst Tries Shear Pin Motor Overld Motor Stall UnderVoltage Power Loss
Defaultx1xx000100001110
Bit 1514131211109876543210
32
