46 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
COMMUNICATION
Comm Control
274 [DPI Port Sel]
Selects which DPI port reference value will appear
in [DPI Port Value].
Default:
Options: 1
2
3
4
5
“DPI Port 1”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“DPI Port 4”
“DPI Port 5”
275 [DPI Port Value]
Value of the DPI reference selected in [DPI Port
Sel].
Default:
Min/Max:
Units:
Read Only
–/+32767
1
Masks/Owners
276 [Logic Mask]
Determines which adapters can control the drive. If the bit for an adapter is set to “0,” the
adapter will have no control functions except for stop.
1 = Control Permitted
0 = Control Masked
288
thru
297
277 [Start Mask]
Controls which adapters can issue start
commands.
See [Logic Mask]
. 288
thru
297
278 [Jog Mask]
Controls which adapters can issue jog commands.
See [Logic Mask]. 288
thru
297
279 [Direction Mask]
Controls which adapters can issue forward/
reverse direction commands.
See [Logic Mask]
. 288
thru
297
280 [Reference Mask]
Controls which adapters can select an alternate
reference; [Speed Ref A Sel], [Speed Ref B Sel] or
[Preset Speed x].
See [Logic Mask]
. 288
thru
297
281 [Accel Mask]
Controls which adapters can select [Accel Time 1]
or [Accel Time 2].
See [Logic Mask]
. 288
thru
297
282 [Decel Mask]
Controls which adapters can select [Decel Time 1]
or [Decel Time 2].
See [Logic Mask]
. 288
thru
297
283 [Fault Clr Mask]
Controls which adapters can clear a fault.
See [Logic Mask]. 288
thru
297
284 [MOP Mask]
Controls which adapters can issue MOP
commands to the drive.
See [Logic Mask]
. 288
thru
297
285 [Local Mask]
Controls which adapters are allowed to take
exclusive control of drive logic commands (except
stop). Exclusive “local” control can only be taken
while the drive is stopped.
See [Logic Mask]
. 288
thru
297
File
Group
No.
Parameter Name & Description Values
Related
Name
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
DPI Port 6
DPI Port 5
DPI Port 4
DPI Port 3
DPI Port 2
DPI Port 1
Digital In
Defaultxxxxxxxxx0111111
Bit 1514131211109876543210
