Allen-Bradley PowerFlex 700H Programming Manual

48 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
COMMUNICATIONS
Datalinks
304
305
[Data In C1] - Link C Word 1
[Data In C2] - Link C Word 2
See [Data In A1] - Link A Word 1 [Data In A2]
- Link A Word 2.
306
307
[Data In D1] - Link D Word 1
[Data In D2] - Link D Word 2
See [Data In A1] -
Link A Word 1 [Data In A2]
- Link A Word 2.
310
311
[Data Out A1] - Link A Word 1
[Data Out A2] - Link A Word 2
Parameter number whose value will be written to
a communications device data table.
Default:
Min/Max:
Units:
0 (0 = “Disabled”)
0/544
1
312
313
[Data Out B1] - Link B Word 1
[Data Out B2] - Link B Word 2
See [Data Out A1] -
Link A Word 1 [Data Out
A2] - Link A Word 2.
314
315
[Data Out C1] - Link C Word 1
[Data Out C2] - Link C Word 2
See [Data Out A1] -
Link A Word 1 [Data Out
A2] - Link A Word 2.
316
317
[Data Out D1] - Link D Word 1
[Data Out D2] - Link D Word 2
See [Data Out A1] - Link A Word 1 [Data Out
A2] - Link A Word 2.
Security
595 [Port Mask Act]
Bits 0…6 indicate status for DPI port communication. Bit 15
indicates when security software is controlling the parameter.
Note: Added for firmware revision 4.001
1 = Active
0 = Not Active
Read Only
596 [Write Mask Cfg]
Enables/disables write access (parameters, links, etc.) for DPI ports. Changes to this parameter
only become effective when power is cycled, the drive is reset or bit 15 of parameter 597 [Write
Mask Act], transitions from “1” to “0.”
Note: Added for firmware revision 4.001.
1 = Write Permitted
0 = Read Only
File Group No.
Parameter Name & Description Values
Related
Name Security Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Host
Default0xxxxxxxx0000000
Bit 1514131211109876543210
Name Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved Reserved DPI Port 6 DPI Port 5 DPI Port 4 DPI Port 3 DPI Port 2 DPI Port 1 Digital In
Defaultxxxxxxxxx1111110
Bit 1514131211109876543210
