INPUTS/OUTPUTS
Digital Outputs
Selected Option Definitions – [Analog Outx Sel], [Digital Inx Sel], [Digital Outx Sel]
381
385
389
[Dig Out1 Level]
[Dig Out2 Level]
[Dig Out3 Level]
Sets the relay activation level for options 10…15
in [Digital Outx Sel]. Units are assumed to match
the above selection (i.e. “At Freq” = Hz, “At
Torque” = Amps).
Default:
Min/Max:
Units:
0.0
0.0
0.0
0.0/1500.0
0.1
380
384
388
382
386
390
[Dig Out1 OnTime]
[Dig Out2 OnTime]
[Dig Out3 OnTime]
Sets the “ON Delay” time for the digital outputs.
This is the time between the occurrence of a
condition and activation of the relay.
Default:
Min/Max:
Units:
0.00 Secs
0.00 Secs
0.00 Secs
0.00/163.00 Secs
0.01 Secs
380
384
388
383
387
391
[Dig Out1 OffTime]
[Dig Out2 OffTime]
[Dig Out3 OffTime]
Sets the “OFF Delay” time for the digital outputs.
This is the time between the disappearance of a
condition and de-activation of the relay.
Default:
Min/Max:
Units:
0.00 Secs
0.00 Secs
0.00 Secs
0.00/163.00 Secs
0.01 Secs
380
384
388
File
Group
No.
Parameter Name & Description Values
Related
Option Description Related
At Speed Relay changes state when drive has reached commanded speed. 380 384 388
Excl Link Links digital input to a digital output if the output is set to “Input 1…6
Link.” This does not need to be selected in the Vector option.
361…366
Input 1-6 Link When Digital Output 1 is set to one of these (i.e. Input 3 Link) in
conjunction with Digital Input 3 set to “Excl Link,” the Digital Input 3
state (on/off) is echoed in the Digital Output 1.
380 384 388
MOP Dec Decrements speed reference as long as input is closed. 361…366
MOP Inc Increments speed reference as long as input is closed. 361…366
Param Cntl (A.O.) Parameter controlled analog output allows PLC to control analog
outputs through data links. Set in [Anlgx Out Setpt], par. 377…378.
342 345
Param Cntl (D.O.) Parameter controlled digital output allows PLC to control digital outputs
through data links. Set in [Dig Out Setpt], parameter 379.
380 384 388
PI Reference Reference for PI block (see Process PI on page 93). 342 345
Run Level
RunFwd Level
RunRev Level
Provides a run level input. A run level input does not require a transition
for enable or fault, but does require a transition for a stop.
361…366
Run w/Comm Allows the Comms start bit to operate like a run with the run input on
the terminal block. Ownership rules apply.
361…366
To Next Page
