2-136 Skip Bands
If a skip band(s) extend beyond the max or min limits, the highest or lowest
band values, respectively, will be clamped at the limit. The center frequency
is recalculated based on the highest and lowest band values. If the band is
outside the limits, the skip band is inactive.
Disabling
If a skip band is not required, its skip frequency value is set to zero.
Range
The skip bands apply to both forward and reverse directions.
}
}
}
400 Hz
0 Hz
Skip Frequency #1
Skip Frequency #2
Max Frequency
Skip Frequency #3
Min Frequency
Skip Frequency #2 (Adjusted)
Skip Frequency #1 (Adjusted)
Skip Frequency #3 (Inactive)

Allen-Bradley PowerFlex Specifications

General

Category	DC Drives
Manufacturer	Allen-Bradley
Series	PowerFlex
Communication Options	EtherNet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure Type	NEMA 1, NEMA 12, NEMA 4/4X
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280 ft) without derating
