Allen-Bradley PowerFlex User Manual

Start-Up 2-157
Basic Start Up (Start,Stop,I/O [2])
Digital
Out 1
Go to 6-1 (D)
StartUp
C. Anlg Outpts
Enter choice for
Analog Out 1 Sel
6-29
StartUp
C. Anlg Outpts
Enter value for
Analog Out 1 Hi
6-30
StartUp
C. Anlg Outpts
Enter value for
Analog Out 1 Lo
6-31
Enter
Enter
StartUp
B. Dig Outputs
Enter choice for
Digital Out 1 Sel
6-25
StartUp
B. Dig Outputs
Enter value for
Dig Out 1 Level
6-26
Enter
StartUp
B. Dig Outputs
Enter choice for
Digital Out 2 Sel
6-27
StartUp
B. Dig Outputs
Enter value for
Dig Out 2 Level
Digital
Out 2
StartUp
B. Dig Outputs
Make a selection
<Digital Out 1>
Digital Out 2
Done
Done
Go to 6-1 (C)
Enter
No
Yes Yes
No
Enter Enter
6-24
Backup
Backup
Enter
Digital Out 1 Sel
= ENUM choice
that uses
"Level"?
Digital Out 2 Sel
= ENUM choice
that uses
"Level"?
