4-3
Select Resistor
Select a resistor bank from Table 4.B or 4.C or your resistor supplier that
has:
• a resistance value that is less than the value calculated (R
db1
in ohms)
• a resistance value that is greater than the minimum resistance listed
in
Table 4.A
• a power value that is greater than the value calculated in
Step 4
(P
av
in watts)
!
ATTENTION: The internal dynamic brake IGBT will be damaged if
the resistance value of the resistor bank is less than the minimum
resistance value of the drive. Use
Table 4.A to verify that the resistance
value of the selected resistor bank is greater than the minimum
resistance of the drive.
