Allen-Bradley PowerFlex User Manual

4-4
Table 4.B Resistor Selection for 240V AC Drives
Ohms Watts
Catalog
Number Ohms Watts
Catalog
Number
154 182 222-1A 45 617 222-5A
154 242 222-1 45 827 222-5
154 408 225-1A 45 1378 225-5A
154 604 225-1 45 2056 220-5A
154 610 220-1A 45 2066 225-5
154 913 220-1 45 3125 220-5
110 255 222-2A 32 875 222-6A
110 338 222-2 32 1162 222-6
110 570 225-2A 32 1955 225-6A
110 845 225-2 32 2906 225-6
110 850 220-2A 32 2918 220-6A
110 1278 220-2 32 4395 220-6
85 326 222-3A 20 1372 222-7A
85 438 222-3 20 1860 222-7
85 730 225-3A 20 3063 225-7A
85 1089 220-3A 20 4572 220-7A
85 1094 225-3 20 4650 225-7
85 1954 220-3 20 7031 220-7
59 473 222-4A
59 631 222-4
59 1056 225-4A
59 1576 225-4
59 1577 220-4A
59 2384 220-4

Allen-Bradley PowerFlex Specifications

General

Category	DC Drives
Manufacturer	Allen-Bradley
Series	PowerFlex
Communication Options	EtherNet/IP, DeviceNet, ControlNet
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Enclosure Type	NEMA 1, NEMA 12, NEMA 4/4X
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-40°C to 70°C (-40°F to 158°F)
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280 ft) without derating
