Digital Inputs 2-51
direction “owner” before it can be used to control direction.
If another device is currently the direction owner (as
indicated by [Direction Owner]), it will not be possible to
start the drive or change direction by using the terminal
block digital inputs programmed for both Run and
Direction control (i.e. Run/Fwd).
Important:
Because an open condition (or unwired condition) commands Forward,
the terminal block seeks direction ownership as soon as this input
function is configured, which may happen at power-up. In order for the
terminal block to actually gain ownership, the masks must be set up
correctly (see above) and no other device can currently have direction
ownership. Once the terminal block gains direction ownership, it will
retain it until shutdown, until the [Direction Mask] or [Logic Mask] bits
for the terminal block are cleared, or until this input function is no longer
configured
• Jog
Jog is essentially a non-latched “run/start” command. An open to closed
transition while drive is stopped causes drive to start (jog) in the current
direction. When the input opens while drive is running (jogging), the
drive will stop.
The drive will not jog while running or while the “Stop - Clear Faults”
input is open. Start has precedence.
The terminal block bit must be set in the [Jog Mask] and [Logic Mask]
parameters in order for the terminal block to cause the drive to jog using
this input function.
• Jog Forward, Jog Reverse
An open to closed transition on one input or both inputs while drive is
stopped will cause the drive to jog unless the “Stop - Clear Faults” input
function is configured and open. The table below describes the actions
taken by the drive in response to various states of these input functions.
!
ATTENTION: If a normal drive start command is received while
the drive is jogging, the drive will switch from jog mode to run
mode. The drive will not stop, but may change speed and/or
change direction.
Jog Forward Jog Reverse Action
Open Open Drive will stop if already jogging, but can be started by other
means. Terminal block relinquishes direction ownership.
Open Closed Drive jogs in reverse direction. Terminal block takes direction
ownership.
Closed Open Drive jogs in forward direction. Terminal block takes direction
ownership.
Closed Closed Drive continues to jog in current direction, but terminal block
maintains direction ownership.
