50 Rockwell Automation Publication 1420-UM001E-EN-P - March 2016
Appendix A PowerMonitor 500 Unit Data Tables
Real-time Metering Values (voltage and current)
Table 11 - Table Properties
CIP Assembly Instance 101
No. of Elements 12
Length in Words 24
Data Type REAL
Data Access Read Only
Table 12 - Real-time Metering Values (voltage and current) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300081 2 V L1-N REAL
1 300083 2 V L2-N REAL
2 300085 2 V L3-N REAL
3 300087 2 V L-N REAL
4 300089 2 V L1-L2 REAL
5 300091 2 V L2-L3 REAL
6 300093 2 V L3-L1 REAL
7 300095 2 V L-L REAL
8 300097 2 A L1 REAL
9 300099 2 A L2 REAL
10 300101 2 A L3 REAL
11 300103 2 A N REAL Calculated by instrument base
