Allen-Bradley PowerMonitor 500

Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 51
PowerMonitor 500 Unit Data Tables Appendix A
Real-time Metering Values (power, PF, frequency)
Table 13 - Table Properties
CIP Assembly Instance 102
No. of Elements 18
Length in Words 36
Data Type REAL
Data Access Read Only
Table 14 - Real-time Metering Values (power, PF, frequency) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300105 2 W L1 REAL
1 300107 2 W L2 REAL
2 300109 2 W L3 REAL
3 300111 2 W  REAL
4 300113 2 VA L1 REAL
5 300115 2 VA L2 REAL
6 300117 2 VA L3 REAL
7 300119 2 VA  REAL
8 300121 2 VAR L1 REAL
9 300123 2 VAR L2 REAL
10 300125 2 VAR L3 REAL
11 300127 2 VAR  REAL
12 300129 2 PF L1 REAL Negative values correspond to lead (C), positive values correspond
to lag (L)
13 300131 2 PF L2 REAL
14 300133 2 PF L3 REAL
15 300135 2 PF  REAL
16 300137 2 Hz REAL
17 300139 2 Voltage phase sequence REAL 1 = L1-L2-L3 voltage rotation
-1 = Not L1-L2-L3 voltage rotation
