Allen-Bradley PowerMonitor 500

52 Rockwell Automation Publication 1420-UM001E-EN-P - March 2016
Appendix A PowerMonitor 500 Unit Data Tables
Maximum Metering Values (voltage and current)
Table 15 - Table Properties
CIP Assembly Instance 103
No. of Elements 12
Length in Words 24
Data Type REAL
Data Access Read Only
Table 16 - Maximum Metering Values (voltage and current) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300337 2 Max V L1-N REAL
1 300339 2 Max V L2-N REAL
2 300341 2 Max V L3-N REAL
3 300343 2 Max V L-N  REAL
4 300345 2 Max V L1-L2 REAL
5 300347 2 Max V L2-L3 REAL
6 300349 2 Max V L3-L1 REAL
7 300351 2 Max V L-L  REAL
8 300353 2 Max A L1 REAL
9 300355 2 Max A L2 REAL
10 300357 2 Max A L3 REAL
11 300359 2 Max A N REAL
