PowerMonitor 500 Unit Data Tables Appendix A
Maximum Metering Values (power, PF, frequency)
Table 17 - Table Properties
CIP Assembly Instance 104
No. of Elements 17
Length in Words 34
Data Type REAL
Data Access Read Only
Table 18 - Maximum Metering Values (power, PF, frequency) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300361 2 Max W L1 REAL
1 300363 2 Max W L2 REAL
2 300365 2 Max W L3 REAL
3 300367 2 Max W  3REAL
4 300369 2 Max VA L1 REAL
5 300371 2 Max VA L2 REAL
6 300373 2 Max VA L3 REAL
7 300375 2 Max VA  REAL
8 300377 2 Max VAR L1 REAL Negative values correspond to lead (C), positive values correspond
to lag (L)
9 300379 2 Max VAR L2 REAL
10 300381 2 Max VAR L3 REAL
11 300383 2 Max VAR  REAL
12 300385 2 Max PF L1 REAL The Max PF displayed corresponds to the PF value with the largest
phase angle.
13 300387 2 Max PF L2 REAL
14 300389 2 Max PF L3 REAL
15 300391 2 Max PF  REAL
16 300393 2 Max Hz REAL
