Appendix A PowerMonitor 500 Unit Data Tables
DMD Metering Values (voltage and current)
Table 19 - Table Properties
CIP Assembly Instance 105
No. of Elements 12
Length in Words 24
Data Type REAL
Data Access Read Only
Table 20 - DMD Metering Values (voltage and current) Data Table
Element Modbus
Address
Length
(words)
Description / Units Data Format Notes
0 300849 2 DMD V L1-N REAL
1 300851 2 DMD V L2-N REAL
2 300853 2 DMD V L3-N REAL
3 300855 2 DMD V L-N  REAL
4 300857 2 DMD V L1-L2 REAL
5 300859 2 DMD V L2-L3 REAL
6 300861 2 DMD V L3-L1 REAL
7 300863 2 DMD V L-L  REAL
8 300865 2 DMD A L1 REAL
9 300867 2 DMD A L2 REAL
10 300869 2 DMD A L3 REAL
11 300871 2 DMD A N REAL
