Appendix A PowerMonitor 500 Unit Data Tables
Table 31 - Configuration - Digital Relay Outputs: Read and Write
Modbus
Address
Length
(words)
Description / Units Data Format Notes
304865 1 Digital output channel 1: enabling UINT 0=Remote
1=Alarm
2= Pulse
304866 1 Digital output channel 1: output
working mode
UINT 0=NO
1=NC (only if selected ‘Alarm’ type)
304867 1 Digital output channel 1: linked
alarm
UINT 0=AL1
1=AL2
2=AL3
3=AL4 (only if selected ‘Alarm’ type)
304868 1 Channel 1: linked counter-variable UINT 0=Total kWh+
1=Total kVARh+
2=Total kWh-
3=Total kVARh-
4=Partial kWh+
5= Partial kVARh+
6= Partial kWh-
7= Partial kVARh-
304869 2 Digital output channel 1: pulse REAL Pulse weight (kWh/pulse or kVARh/pulse)
Value min = 0.001
Value max = 9999.9
304871 1 Digital output channel 2: enabling UINT 0=Remote
1=Alarm
2= Pulse
304872 1 Digital output channel 2: output
working mode
UINT 0=NO
1=NC (only if selected ‘Alarm’ type)
304873 1 Digital output channel 2: linked
alarm
UINT 0=AL1
1=AL2
2=AL3
3=AL4 (only if selected ‘Alarm’ type)
304874 1 Channel 2: linked counter-variable UINT 0=Total kWh+
1=Total kVARh+
2=Total kWh-
3=Total kVARh-
4=Partial kWh+
5= Partial kVARh+
6= Partial kWh-
7= Partial kVARh-
304875 2 Digital output channel 2: pulse REAL Pulse weight (kWh/pulse or kVARh/pulse)
Value min = 0.001
Value max = 9999.0
