Allen-Bradley PowerMonitor 500

Rockwell Automation Publication 1420-UM001E-EN-P - March 2016 61
PowerMonitor 500 Unit Data Tables Appendix A
Table 32 - Commands: Write-only
Modbus
Address
Length
(words)
Description / Units Data Format Notes
312369 1 Get clock values UINT Value=1 - command executed; Value≠1 - no effect
312370 1 Set clock values UINT Value=1 - date and time set
312374 1 Enable optional pulse (digital) outputs UINT Value=1 - module enabled; Value=0 - module disabled
312376 1 Enable optional serial communication UINT Value=1 - module enabled; Value=0 - module disabled
312546 1 Reset all pulse (digital) outputs (digital
output 1 or 2)
UINT Value=1 - command executed; Value≠1 - no effect
312547 1 Set pulse (digital) output 1 UINT Value=0 - reset output; Value=1 - set output; Other values - no
effect
312548 1 Set pulse (digital) output 2 UINT Value=0 - reset output; Value=1 - set output; Other values - no
effect
312549 1 Set all pulse (digital) outputs (digital
output 1 or 2)
UINT Value=1 - command executed; Value≠1 - no effect
312802 1 Reset V L1-N UINT 16 Bit0 = 1: Reset Max Value
Bit1 = 1: Reset DMD value
Bits 2 … 15: Reserved
312803 1 Reset V L2-N UINT 16
312804 1 Reset V L3-N UINT 16
312805 1 Reset V L-N  UINT 16
312806 1 Reset V L1-L2 UINT 16
312807 1 Reset V L2-L3 UINT 16
312808 1 Reset V L3-L1 UINT 16
312809 1 Reset V L-L  UINT 16
312810 1 Reset A L1 UINT 16
312811 1 Reset A L2 UINT 16
312812 1 Reset A L3 UINT 16
312813 1 Reset A N UINT 16
