Publication 2711-UM014B-EN-P
Running Applications 5-5
Cursor - Piloted Control Lists
On a piloted control list, some items are under controller operation
only. In addition, some items may be designated as inactive. You
cannot select controller items or inactive items. In both cases, the
cursor is hollow when you select the item.
To select an item on a control list:
1. Select the control list by:
• touching the screen object (touch screen terminals only)
• or pressing its function key
• or pressing the Left or Right arrow keys until the control
list has a vertical bar indicating it is active
2. Move the cursor up or down the list using the Up
or Down
arrows. If the cursor is hollow, the item cannot be selected.
3. Depending on the application design, you may or may not have
to press
↵ to enter the selection indicated by the cursor.
State 1
State 4
State 5
State 1
State 2
State 3
State 4
State 5
State 2
State 3
State 1
State 5
State 2
State 3
State 4
State2
Cursor at state 2,
an active state
Cursor at inactive state 3,
Cursor changes and highlight
remains in original position
Cursor at inactive state 3,
Cursor changes and highlight
remains in original position
Cursor at active state 4,
Cursor changes back and
highlight moves to selection
Active State
Inactive State
Active State
