Publication 2711-UM014B-EN-P
5-10 Running Applications
ASCII Scratchpad - 300 Micro/300 Terminals
The thumbwheel scratch pad allows an operator to enter values on
terminals without a numeric keypad or touch screen by cycling
through the available characters one position at a time. This is the
character sequence:
The default scratchpad indicates <space>. Pressing the Up or Down
cursor keys on a <space> cycles through the available characters
beginning at A. Pressing the Down cursor cycles back through the list
beginning at 9.
The scratchpad has the following function keys:
Keys Function
F1 - ESC Exits the scratchpad without saving any changes or
sending characters to the logic controller.
F2 - Clear Clears all characters in the display area.
F3 - INS Inserts a space at the current cursor position.
F4 - DEL Deletes the character at the current cursor position.
<space> A - Z, a - z, + - = ( ) [ ] { } < > / \ $ & @ ‘ “ , . ; : ? ! % # * _ ^ ~ ` ¬ ¡ ¿
ß ° £ ç Ç µ â à á ä Ä ê è é É î ì í Ñ ñ ô ò ó ö Ö û ù ú ü Ü, 0 - 9
