Allen-Bradley PV300 Micro User Manual

Publication 2711-UM014B-EN-P
Terminal Overview 1-3
PanelView 550 Monochrome Terminals
The Touch Screen version of the PanelView 550 terminal is available
only with 24V dc power. The L1 in the catalog number indicates DC
power.
1
Add L1 to the end of the catalog number for 24V dc power.
Add l2 to the end of a catalog number for stainless steel. Not available for the touch screen terminals.
Add L3 to the end of a catalog number for 24V dc power and stainless steel. Stainless steel is not available for
the touch screen terminals.
Operator
Input
Communication Port
Printer Port
RS-232
Catalog
Number
1
RIO DH-485 RS-232
(DH-485)
DH+ DeviceNet ControlNet RS-232
(DF1)
Ethernet
Touch Screen
and Keypad
x x 2711-B5A1
x 2711-B5A2
x x 2711-B5A3
x 2711-B5A5
xx2711-B5A8
xx2711-B5A9
xx2711-B5A10
xx2711-B5A15
xx2711-B5A16
xx2711-B5A20
Keypad
x x 2711-K5A1
x 2711-K5A2
x x 2711-K5A3
x 2711-K5A5
xx2711-K5A8
xx2711-K5A9
xx2711-K5A10
xx2711-K5A15
xx2711-K5A16
xx2711-K5A20
Touch
Screen
(24V dc only)
x x 2711-T5A1L1
x 2711-T5A2L1
x x 2711-T5A3L1
x 2711-T5A5L1
xx2711-T5A8L1
xx2711-T5A9L1
xx2711-T5A10L1
xx2711-T5A15L1
xx2711-T5A16L1
xx2711-T5A20L1
