Publication 2711-UM014B-EN-P
12-30 Terminal Connections
Typical ControlNet Network
Below is a typical ControlNet network with a PanelView terminal
installed on a network drop.
PanelView 1000
ControlNet Port
BNC Coaxial Cable
RS-232 Port
Printer
PLC-5/40C
Serial Link
PLC-5/80C
Repeater
(1786-RPT)
1786-RG6 Cable
Serial Link
1770-KFC
Flex I/O
(1784-ACN)
= Taps
= Terminators
Personal
Computer
Personal
Computer
1784-KTC(X)
1784-KTC(X) Card to
ControlNet (RSLinx) & WinPFT
Computer for developing
PanelView applications
ControlLogx 5550
1756-CNB Module
OR
Interface Card
To Next Page
