Publication 2711-UM014B-EN-P
12-32 Terminal Connections
NAP and Redundant Cables
ControlNet cables, taps, connectors. Refer to the ControlNet Cable
System Planning and Installation manual (Publication 1786-6.2.1) for
descriptions of these components. For information on purchasing
these items, refer to the Allen-Bradley ControlNet Cable System
Component List (Publication AG-2.2).
Item Catalog Number
RG-6 quad-shield 1786-RG6
Coax repeater 1786-RPT, -RPTD
Coax taps 1786-TPR, -TPS, -TPYR, -TPYS
Network access cable 1786-CP
Coax tool kit 1786-CTK
Segment terminators 1786-XT
BNC connectors 1786-BNC, -BNCJ, -BNCP, -BNCJ1
IMPORTANT
Do not connect to a network using both the
redundant cable BNC connector and the Network
Access Port (NAP).
