Publication 2711-UM014B-EN-P
Terminal Connections 12-37
Ethernet Connector
The Ethernet connector is an RJ45, 10/100Base-T connector. The
pinout for the connector is shown below:
When to use a straight-through and cross-over pin-out:
• Direct point-to-point 10/100Base-T cables, with cross over
pin-out (1-3, 2-6, 3-1, 6-2), connect the PanelView Ethernet port
directly to another SLC 5/05 Ethernet port (or a computer 10/
100Base-T port).
Cables
Category 5 shielded and unshielded twisted-pair cables with RJ45
connectors are supported. The maximum cable length between the
PanelView Ethernet port and a 10/100Base-T port on an Ethernet hub
(without repeaters or fiber) is 100 meters (328 feet). However, in an
industrial application, the cable length should be kept to a minimum.
Pin Pin Pin Name
RJ45
Connector
1TD+
2TD-
3RD+
4NC
5NC
6RD-
7NC
8NC
ATTENTION
!
If you connect or disconnect the Ethernet cable with
power applied to the PanelView or any device on
the network, an electrical arc can occur. This could
cause an explosion in hazardous location
installations. Be sure that power is removed or the
area is nonhazardous before proceeding.
