Allen-Bradley PV300 Micro User Manual

Publication 2711-UM014B-EN-P
Terminal Connections 12-41
Connecting to an Advanced Interface Converter
DH-485 versions of the PanelView 300 Micro can operate on a DH-485
network through an Advanced Interface Converter (AIC+) module.
Use the following cables.
Connecting to a DeviceNet Interface (DNI)
Operate the PanelView 300 Micro on a DeviceNet network using DF1
protocol through a point-to-point connection to a DNI module.
RS-232 Communications Port
1
3
2
5
4
8
7
6
PanelView 300 Micro
Cable, Catalog No. 1761-CBL-AM00, Series C (.5 m, 1.5ft)
Cable, Catalog No. 1761-CBL-HM02, Series C (2 m, 6.5 ft)
Cable, Catalog No. 2711-CBL-HM05, Series C (5m, 15 ft)
Cable, Catalog No. 2711-CBL-HM10, Series C (10m, 30ft)
1
3
2
5
4
87
6
15
6
9
Cable, Catalog No. 1761-CBL-AP00, Series C (.5 m, 1.5ft)
Cable, Catalog No. 1761-CBL-PM02, Series C (2 m, 6.5 ft)
Cable, Catalog No. 2711-CBL-PM05, Series C (5m, 15 ft)
Cable, Catalog No. 2711-CBL-PM10, Series C (10m, 30ft)
1761-CBL-AP00
1761-CBL-PM02, 2711-CBL-PMxx
(to Port 1 of AIC+)
1761-CBL-AM00
1761-CBL-HM02, 2711-CBL-HMxx
(to Port 2 of AIC+)
Refer to previous sections for cable diagrams.
AIC+
(to Port 1)
(to Port 2)
Port 2
Port 1
RS-232 Communications Port
RS-232 Comm Port
Cable, Catalog No. 1761-CBL-AM00, Series C (.5 m, 1.5ft)
Cable, Catalog No. 1761-CBL-HM02, Series C (2 m, 6.5 ft)
Cable, Catalog No. 2711-CBL-HM05, Series C (5m, 15 ft)
Cable, Catalog No. 2711-CBL-HM10, Series C (10m, 30ft)
1
3
2
5
4
87
6
1
3
2
5
4
87
6
1761-CBL-AM00
1761-CBL-HM02
2711-CBL-HMxx
V±
D
V+
NET
MOD
NODE
TX/RX
PanelView 300 Micro
Pin #
1
2
3
6
5
4
7
8
1 24V
2 GND
3 RTS
6 CTS
5 DCD
4 RXD
7 TXD
8 GND
Pin #
24V
GND
RTS
CTS
DCD
RXD
TXD
GND
Cable Connector
Cable Connector
