Publication 2711-UM014B-EN-P
Configuring the Terminal 3-27
Normal Intensity
Adjusts the intensity of the display with each key press: 25, 50, 75,
100. The new setting takes effect immediately.
Reset Video
Resets the display to normal video (default settings).
On keypad terminals, the reset video [F15] key is also active on the
Configuration Mode menu. If the screen is non-viewable, press the
Left and Right arrow keys simultaneously. Then press [F15] to
reset the screen.
Align Touch Grid - PV1400 Touch Screen only
Opens the touch alignment screen, which lets you realign the screen
with the touch grid. This function is useful when the terminal is
positioned at an angle and viewing the screen is difficult unless you
realign the screen.
Move the screen until it aligns with the touch cells. Alignment changes
are permanent.
Exit
Returns to the Configuration Mode menu.
Press: To:
Move the screen up one pixel.
Move the screen down one pixel.
Move the screen to the right 2 pixels.
Move the screen to the left 2 pixels.
Move the screen to its factory default position.
Exit Exit the touch alignment screen and return to Screen Setup.
F16
EXIT
