Specifications
Additional Resources
These documents contain additional information concerning related products from Rockwell Automation.
You can view or download publications at
http://www.rockwellautomation.com/global/literature-library/overview.page. To order paper copies of
technical documentation, contact your local Allen-Bradley distributor or Rockwell Automation sales representative.
Rockwell Automation Support
For technical support, visit http://www.rockwellautomation.com/support/overview.page.
Attribute 1783-US5T Series B 1783-US8T Series B
1783-US4T1F Series B,
1783-US4T1H Series B,
1783-US16T Series B,
1783-US16T2S Series B
1783-US6T2F Series B, 1783-US6T2H Series B,
1783-US7T1F Series B, 1783-US7T1H Series B,
1783-US8TG2GX Series B,
1783-US6T2TG2F Series B,
1783-US6T2TG2H Series B
1783-US5TG Series B
Temperature, operating -10 °C < Ta < +60 °C (14 °F < Ta < +140 °F) -40 °C < Ta < +75 °C (-40 °F < Ta < +167 °F)
Temperature, ambient, max 60 °C (140 °F) 75 °C (167 °F)
Temperature, surrounding air, max 60 °C (140 °F) 75 °C (167 °F)
Enclosure type rating None (open-style)
Power input 24V (12…48V DC, 18…30V AC, 50…60 Hz), SELV
Wire size, power connections 4…0.25 mm
2
(12…24 AWG) twisted-pair copper wire suitable for 86 °C (187 °F) above surrounding ambient temperature outside the enclosure
Wire size, functional earth 2.5 mm
2
(14 AWG) copper wire suitable for 86 °C (187 °F) above surrounding ambient temperature outside the enclosure, with a suitable ring terminal
Screw torque, ground terminal, max 0.91 N•m (8.05 in•lb)
Screw torque, power terminals 0.50…0.56 N•m (4.5…5.0 in•lb)
North American temp code T4 T4 T5 T4 T4A
ATEX temp code T4 T4 T4 T4 T4
IECEx temp code T4 T4 T4 T4 T4
Resource Description
Stratix Ethernet Managed Switches Technical Data, publication 1783-TD001 Provides specification information for the switches.
Stratix 2000 Ethernet Unmanaged Switches User Manual, publication 1783-UM011 Describes the operation of the DIP switches and status indicators on the switch.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation industrial system.
Product Certifications website, rok.auto/certifications Provides declarations of conformity, certificates, and other certification details.
