Rockwell Automation Publication 1783-UM001B-EN-P - May 2010 11
Chapter
1
Basic Configuration
What This Chapter Contains
This chapter covers how to use the Home web page options. It also includes
information about how to set an IP address and security, work with
Miscellaneous options, and understand status indicators.
Access the Home Page
To access the Home page, perform this procedure.
1. Connect the switch to your computer’s LAN card. This connection is
required before you can access the Home page.
For information about how to establish this connection, see the
Stratix 6000 Ethernet Managed Switch Installation Instructions,
publication 1783-IN004
.
2. Open your web browser once the connection is established.
3. In the address bar of your web browser, type your switch's IP address, for
example, http://192.168.1.1 (192.168.1.1 is the default IP address).
4. From the user name and password dialog box, keep the user name empty
and type the password of 'PASSWORD'.
If the web browser does not open, verify:
• the IP address of the switch; 192.168.1.1 is the default.
• your connection setup, referring to the Stratix 6000 Ethernet Managed
Switch Installation Instructions, publication 1783-IN004
for further
guidance, if needed.
• the switch has power (green power status indicator is on).
• the cable is connected (you see a green or yellow status indicator lit on
the Ethernet port).
• a proxy server is not preventing you from accessing the switch.
IMPORTANT
Before connecting to the network, set the IP address of the
switch as described in Set the IP Address
.
