Appendix D Data Layout
DINT Output
This table shows the data layout.
Bit Bit
0
1
2
3
4
5
6
7
8
9…31
Shut down All Ports (disables all comms)
Shut down Port 1
Shut down Port 2
Shut down Port 3
Shut down Port 4
Shut down Port 5
Shut down Port 6
Shut down Port 7
Shut down Port 8
Reserved
