Rockwell Automation Publication 1783-UM001B-EN-P - May 2010 73
Appendix
H
Available SFP Modules and Cables
What This Appendix
Contains
This appendix provides information about the small form-factor pluggable (SFP)
module and cabling used with the 1783-EMS08T switch.
Available SFP Modules
Available SFP modules include the following:
• 1783-SFP1GSX - 1000BASE-SX multi-mode fiber transceiver
• 1783-SFP1GLX - 1000BASE-LX single-mode fiber transceiver
SFP Module Cable
Specifications
The following table lists the cable specifications for the fiber-optic SFP module
connections.
Each port must match the wave-length specifications on the other end of the
cable. For reliable communication, the cable must not exceed the rated maximum
cable length.
TIP
For detailed instructions on installing, removing, and connecting the
SFP modules, see the documentation that shipped with the SFP
module.
SFP Module Type Cat. No. Wave-
length
(mm)
Fiber Type Core Size/
Cladding
Size
(micron)
Modal Band-
width (MHz/
km)
(1)
Cable Distance
1000BASE-SX 1783-SFP1GSX 850 MMF 62.5/125
62.5/125
50/125
50/125
160
200
400
500
220 m (722 ft)
275 m (902 ft)
500 m (1640 ft)
550 m (1804 ft)
1000BASE-LX/LH 1783-SFP1GLX 1310 SMF G.652 - 10 km (32,810 ft)
(1) Modal bandwidth applies only to multimode fiber.
