Publication 2092-UM001D-EN-P — July 2005
C-2 Catalog Numbers and Accessories
Ultra1500 Drives
Use the following table to identify Ultra1500 drives based on Continuous
Output Current, or Intermittent Output Current.
Ultraware Software
The Ultra1500 drives are configured using Ultraware. Ultraware is a
Windows
®
based application that allows drive configuration to be done
off-line and saved to disk.
AC Line Filters
Use the following table to identify the AC Line Filter for your application.
Continuous Output Current Intermittent Output Current Catalog Number
1.4A (0–peak) 3.4A (0–peak) 2092-DA1
2.4A (0–peak) 7.2A (0–peak) 2092-DA2
4.7A (0–peak) 11.3A (0–peak) 2092-DA3
10.7A (0–peak) 24.8A (0–peak) 2092-DA4
16.4A (0–peak) 43.4A (0–peak) 2092-DA5
Description Catalog Number
Ultraware Software 2098-UWCPRG
AC Line Filter Description
AC Line Filter
Fuse Block
Catalog Number
AC Line Filter (single phase) for 2092-DA1 and
2092-DA2 drives
6 Amp 2090-UXLF-106
AC Line Filter (single phase) for 2092-DA3 drive 10 Amp 2090-UXLF-110
AC Line Filter (three-phase) for 2092-DA4 and
2092-DA5 drive
23 Amp 2090-UXLF-HV323
