Publication 2092-UM001D-EN-P — July 2005
D-30 Ultra1500 Operator Interface
Pr-6.05 Reserved
Pr-6.06 Fault Detail Setup: Sample Period
Pr-6.07 Fault Detail Setup: Channel A
Pr-6.08 Fault Detail Setup: Channel B
Pr-6.09 Fault Detail Setup: Channel C
Default: 0
Applicable Operating Mode: Follower, Analog Velocity, Preset Velocity
Ultraware Link: Main Velocity Regulator Gains: D
This parameter is Reserved.
Description:
The time, in 0.2 msec increments, between signal samples.
50 samples constitute a fault trace.
Range: 1 to 99
Default: 5
Units: 0.2 msec
Ultraware Link: Fault Detail Setup: Sample Period
Description: Selects the drive signal to assign to a Channel A.
Range:
See Monitor Variable Numbers (except 0x0F) beginning on
page D-6.
Default: 0x00
Ultraware Link: Fault Detail Setup: Channel A
Description: Selects the drive signal to assign to Channel B.
Range:
See Monitor Variable Numbers (except 0x0F) beginning on
page D-6.
Default: 0x03
Ultraware Link: Fault Detail Setup: Channel B
Description: Selects the drive signal to assign to Channel C.
Range:
See Monitor Variable Numbers (except 0x0F) beginning on
page D-6.
Default: 0x0B
Ultraware Link: Fault Detail Setup: Channel C
