Factory Tests
Test Name Display Description
Machine Type Tumbler Tumbler
Control Software Version XXX.YYY.ZZZ XXX is the control software version num-
ber, YYY is the internal release target and
ZZZ is the internal development version.
Display Software Version XXX.YYY.ZZZ XXX is the control software version num-
ber, YYY is the internal release target and
ZZZ is the internal development version.
I/O Board Software Version XXX.YY XXX is the I/O board version number and
YY is the I/O board software subversion
number.
Drive Software Version Drive: XX
Fan: YY
XX is the drive motor software version
number. YY is the fan motor software ver-
sion number.
ICM Software Version (gas only) XX XX is the ICM software version number.
Control Level 1 Touch
Capacity YXXX XXX is the capacity in pounds. Y is the
machine type identifier (T=stacks, F=fast
dry, no character is everything else).
Touch Screen Test Touch START to begin The display instructs the operator to touch
various display locations.
Display Test This test will display a sequence of pat-
terns.
Audio will sound after start is touched.
Touching the screen will advance to the
next.
Service Door Switch Test "Open" or "Closed" Displays the state of the service door
switch.
Coin Vault Switch Test "Open" or "Closed" Displays the state of the coin vault switch.
Coin Drop Test Coin Drop Test
Coin 1: X
Coin 2: Y
X and Y are the number of pulses received
for drop #1 and drop #2.
Door Switch Test "Open" or "Closed" The display will show the switch state,
"Open" or "Closed".
Lint Door Test "Open" or "Closed" The display will show the switch state,
"Open" or "Closed".
Heat Configuration "Heat Configuration" and "Electric
Heat", "Steam Heat", "Gas Domestic" or
"Gas EU"
Temperature: XXY
XX is the temperature and Y is the units
(Celsius or Fahrenheit).
Table 6 continues...
Diagnostics Menu
©
