Allison Transmission 3000

To Next Page

To Previous Page

Figure4–3.ShiftSelectorTransitionandOilFieldPumping

(InputFunctionBZ:Wire142)

WARNING:Thisschematicshowstheintendeduseofthespecied

controlsfeaturewhichhasbeenvalidatedintheconguration

shown.Anymiswiringoruseofthisfeaturewhichdiffersfromthat

showncouldresultindamagetoequipmentorproperty,personal

injury,orlossoflife.AllisonTransmissionisnotliableforthe

consequencesassociatedwithmiswiringorunintendeduse

ofthesefeatures.
