Revision G04 July 2018
Figure 14: MechFiber 340 with BaleBlend attachment
8.6 SHEAR BOLTS
The following are the recommended shear bolts to be used with the KEENAN
MechFiber340 & MechFiber360.
Machine type Shaft Shear Bolt
MechFiber340 & 360 T60 M10 x 65 x 8.8
Table 5: Shear bolt
CAUTION:
Failure to use the correct grade of shear bolt can
result in overload failure of the machine and will
invalidate your warranty.
32
BaleBlend Creel
BaleBlend Tines
Cradle Arms
Load Bumper Assembly
