Revision G04 July 2018

11.10 BODY SEALING PARTS

Item: P/N Qty: Description:

MechFiber340 MechFiber360

1 FP140-004-0003 FP200-004-0028 1 VFC door inner seal retainer

2 701290 701293 1 VFC Door inner rubber seal – 5005mm

3 FP280-010-009 FP280-010-009 2 VFC door front and rear end retainer

4 704876 704876 2 VFC door front and rear end seal

5 N/A 704880 4 VFC door outer end seal rubber

6 FP140-006-0022 FP200-006-0076 6 VFC door shroud seal retaining at

7 701195 701199 4/2 VFC door outer seal rubber

8 FP160-006-0093 FP160-006-0093 1 Auger chamber material deector

Table 20: Body Seal

Note:

MechFiber360 uses 2 types of VFC Door Outer Seals, 701199 for the middle section of the auger

chamber and 704880 (a shorter version) for either end.
