Item: P/N: Qty: Description:
1 FP160-006-0429 1 Feed Out Shroud Front Side Plate Assembly
2 FP160-006-0430 1 Feed Out Shroud Rear Side Plate Assembly
3 FP160-006-0432 1 Feed Out Shroud Top Plate
4 FP160-006-0088 1 Hinge Bracket, Feed Out Door RHS
5 FP160-006-0087 1 Hinge Bracket, Feed Out Door LHS
6 FP160-006-0090 1 Feed Out Door Assembly
7 FP160-006-0123 1 Std Tray Assembly with Rubber Extension (P/N 701403)
8 FP160-006-0044 1 Feed Out Tray Ram mounting plate assembly
9 703591 1 6” Stroke Hydraulic Ram (KEEN-63)
10 FP080-006-0012 2 Feed Out Door Link Arm
11 FP160-006-0072 1 Feed Out Rubber Shroud, Rubber Curtin
12 FP300-006-0095 2 Feed Out Door Shroud Retainer
13 FP300-006-0096 2 Feed Out Door Shroud Side Retainer
14 700732 7 M16 Flat Washer
15 700736 6 M8 Flat Washer
16 700223 26 M8 NyLock Nut
17 700210 2 M8 x 25 Set Screw (HT)
18 700249 4 M12 x 35 Set Screw
19 700208 4 M8 x 20 Set Screw
20 702111 2 M10 x 30 Set Screw
21 700729 6 M10 Flat Washer
22 700266 4 M12 Lock Nut
23 700241 2 M10 Lock Nut
24 700730 2 M12 Flat Washer
25 700275 2 M16 x 50 Bolt
26 700283 4 M16 Lock Nut
27 700281 2 M16 x 90 Bolt
28 FP160-006-0124 1 Std Feedout Tray Assembly
29 701403 1 Feed Out Rubber Extension (standard)
30 EF106-79 2 Feed Out Tray Side Rubber Retainer
31 FP160-006-0224 1 Rubber Retainer
32 705405 9 M12 x 40 Cup Head Bolt
33 700266 9 M12 Lock Nut
34 700730 9 M12 Flat Washer
35 FP160-006-0270 3 Tray Magnet Hole Blanking Plate (Standard)
35a 701366 3 Magnet Plate (OE)
36 702256 18 M8 x 25 Cup Head Bolt
37 700736 18 M8 Flat Washer
38 700223 18 M8 Nylock Nut
Table 18: Feed-Out Tray Details (Both MechFiber 340 & 360)
Note:
Complete Standard Feed-Out Kit P/N FP160-006-0428
Feed Out Tray can be supplied with the Magnet Assembly P/N FP160-006-0071
51
Revision G04 July 2018
