Revision G04 July 2018
54
Item: P/N: Qty: Description:
1 FP160-006-0417 1 Fold Down Tray Shelf Assembly
2 FP170-006-0182 1 Fold Down Tray Hinge Bar Assembly
3 FP170-006-0191 1 Fold Down Tray Assembly & Rubber
4 FP160-006-0044 1 Fold Down Tray Mounting Plate Assembly
5 FP170-006-0162 1 Fold Down Tray Inner Link Arm Assembly
6 FP200-006-0340 1 Fold Down Tray Outer Link Arm Assembly
7 705268 1 6” Ram Assembly with Check Valve (KEEN-63SP)
8 FP200-006-0332 1 Fold Down Tray Outer Link Arm -127mm Centres
9 FP160-006-0427 1 Feed Out Shroud Rubber Assembly
10 FP160-006-0061 1 Rubber Retainer 1400mm Wide
11 FP160-006-0420 2 Fold Down Tray Shelf to Auger Chamber Tie Plate
12 FP170-006-0156 1 Feed Out Tray Ram Bracket Spacer Bush
13 700241 1 M10 Lock Nut
14 700250 9 M12 x 40 Set Screw
15 700266 9 M12 Lock Nut
16 700280 1 M16 x 80 Bolt
17 700268 1 M16 x 100 Bolt
18 700283 5 M16 Lock Nut
19 700302 1 M20 x 90 Bolt HT
20 700305 3 M20 Nylock Nut
21 700729 1 M12 Locknut
22 700730 18 M12 Flat Washer
23 700732 7 M16 Flat Washer
24 700733 3 M20 Flat Washer
25 701488 2 M20 x 110 Bolt HT
26 700226 1 M10 x 30 Cup Head Bolt
27 700269 1 M16 x 110 Bolt
28 700274 2 M16 x 45 Bolt
29 FP170-006-0187 1 Feed Out Shroud Rubber Lower Retainer Plate
30 FP160-006-0422 1 Feed Out Shroud Rubber
31 700241 5 M10 Lock Nut
32 700729 5 M10 Flat Washer
33 700251 5 M10 x 40 Cup Head Bolt
34 FP170-006-0188 5 Retainer Plate Washer
35 FP170-006-0178 1 Fold Down Tray Assembly
36 FP170-006-0186 1 Fold Down Tray Rubber Extension
37 FP160-006-0224 1 Rubber Retainer
38 EF106-79 2 Side Rubber Retainer Plate
39 FP160-006-0272 3 Tray Magnet Hole Blanking Plate (Standard)
To Next Page
